AISI 904L is an austenitic stainless steel that offers a strong resistance to reducing acids such as Sulphuric acid aswell as a good resistance to crevice, pitting, intergranular and stress corrosion. 904L also offers both good weldability and formability with maximum service temperatures reaching 450°C.
Chemical Composition (Max %)
|
Grade |
Ni |
Cr |
Mo |
Cu |
C |
Mn |
Si |
P |
S |
Fe |
|
904L |
23 – 28 |
19 – 23 |
4 -5 |
1 – 2 |
0.02 |
2 |
1 |
0.045 |
0.035 |
Balance |
Mechanical Properties
|
Grade |
Tensile Strength, Min |
Yeild Strength, Min |
Elognation |
Hardness |
|
904L |
490 Mpa |
215 Mpa |
35% |
90 HRB Max |
Physical Properties
|
Grade |
Density |
Elastic Modulus |
Mean Co-Eff Of |
Thermal Conductivity |
Specific Heat 0-100°C |
Elec Resistivity |
|||
|
0-100°C |
0-315°C |
0-538°C |
At 20°C |
At 500°C |
|||||
|
904L |
7900 |
190 |
15 |
– |
– |
11.5 |
– |
500 |
952 |
Standards
ASTM A 312–seamless, welded, and heavily cold worked austenitic stainless steel pipes
ASTM B 673–uns n08904, uns n08925, and uns n08926 welded pipe
ASTM B 677–uns n08904, uns n08925, and uns n08926 seamless pipe and tube
ASTM A 213–seamless ferritic and austenitic alloy-steel boiler, super heater, and heat-exchanger tubes
ASTM A 249–welded austenitic steel boiler, super heater, heat-exchanger, and condenser tubes
ASTM A 269–seamless and welded austenitic stainless steel tubing for general service
ASTM B 674–uns n08904, uns n08925, and uns n08926 welded tube
ASTM B 677–uns n08904, uns n08925, and uns n08926 seamless pipe and tube
Applications
Petroleum and petrochemical equipment, for example: Reactor
Storage and transportation equipment of sulphuric acid, for example: heat exchanger
Sea water treatment equipment, sea water heat exchanger
Paper industry equipment, sulfuric acid, nitric acid equipment, making acid, pharmaceutical industry
Pressure vessel
Food equipment
